4th Gen SiC MOSFET Simulation Models for PSIM™ Now Available

ROHM has begun offering 4th Gen SiC MOSFET simulation models compatible with PSIM™, a circuit simulator designed for power electronics and motor drive developed by Altair®. Designers can now easily download model files to perform system-level evaluations, allowing for efficient design and evaluation across a wire range of industrial sectors, further promoting the use of power devices.

PSIM™

PSIM™ Features

・ Provides robust, high-speed simulation of power converters and motor drives
・ Easily create main and control circuits with an intuitive GUI
・ Integration with Altair’s multi-physics platform enables high-fidelity temperature predictions through CFD coupling

Featured Products

Part Number Drain-source Voltage[V] Drain-source On-state Resistance
(Typ.(mΩ)		 Package PSIM
Model
SCT4045DE 750 45
TO-247N		 Available
SCT4026DE 26 Available
SCT4013DE 13 Available
SCT4062KE 1200 62 Available
SCT4036KE 36 Available
SCT4018KE 18 Available
SCT4045DR 750 45
TO-247-4L		 Available
SCT4026DR 26 Available
SCT4013DR 13 Available
SCT4062KR 1200 62 Available
SCT4036KR 36 Available
SCT4018KR 18 Available
SCT4045DW7 750 45
TO-263-7L		 Available
SCT4026DW7 26 Available
SCT4013DW7 13 Available
SCT4062KW7 1200 62 Available
SCT4036KW7 36 Available
SCT4018KW7 18 Available

Related Information

・ROHM 4th Gen SiC MOSFETs
・ROHM Design Models

About PSIM™

*PSIM™ is a trademark of Altair®
