Combine with 8 different sensor evaluation boards to facilitate set development for the IoT market

ROHM today announced the availability of a new sensor shield (expansion board) equipped with 8 sensor boards (e.g. accelerometer, barometric pressure, geomagnetic, heart rate sensors, etc.) designed for use with existing open platform MCU boards such as Arduino, and mbed.

The SensorShield-EVK-003 is the latest sensor evaluation kit offered by ROHM. The updated kit bundles 8 individual sensor boards produced by the ROHM Group (including a new optical heart rate sensor) along with a shield board for connecting to open platforms, making it easy to configure a sensor environment by simply incorporating software and connecting to Arduino Uno or other popular MCU board. This enables immediate verification of sensor operation and facilitates the design of sensor devices, significantly reducing development load while promoting the expansion of the IoT market.

In addition to meeting user demands for a kit (SensorShield-EVK-003), the sensor shield and sensor evaluation boards are available for purchase separately through online distributors. Additionally, all documents and materials necessary for operating the sensor kit can be downloaded from our website.

In recent years, following the proliferation of IoT in infrastructure, agriculture, automotive, and other areas, many companies have emerged, offering services, applications, and devices to meet the needs of the IoT market. However, significant development effort along with hardware and software expertise is required when creating products for the expanding IoT ecosystem. Additionally, the development and mounting environment for each IoT device will inherently differ, preventing easy evaluation.

In response, the ROHM Group began offering open source platform tools such as the Lazurite series that facilitate IoT prototyping and initial development. Moving forward ROHM will continue to develop sensor devices that achieve greater comfort and safety in the IoT and other expanding markets.

Availability: Now
Pricing: $148.80/kit

Product Lineup

Product Name	Part No.	Onboard Sensor P/N	Image
Arduino-Compatible Sensor Shield (Bundled w/8 Sensor Boards)	SensorShield-EVK-003	-
Arduino-Compatible Sensor Shield (No Sensor Boards)	SHIELD-EVK-001	-
Accelerometer Evaluation Board	KX224-I2C-EVK-001	KX224-1053
Barometric Pressure Sensor Evaluation Board	BM1383AGLV-EVK-001	BM1383AGLV
Geomagnetic Sensor Evaluation Board	BM1422AGMV-EVK-001	BM1422AGMV
Ambient Light/Proximity Sensor Evaluation Board	RPR-0521RS-EVK-001	RPR-0521RS
Color Sensor Evaluation Board	BH1749NUC-EVK-001	BH1749NUC
Hall IC Evaluation Board	BD7411G-EVK-001	BD7411G
Temperature Sensor Evaluation Board	BD1020HFV-EVK-001	BD1020HFV
Heart Rate Sensor Evaluation Board	BH1790GLC-EVK-001	BH1790GLC

* BH1792GLC-EVK-001 is sold individually.

Supporting Materials

All required materials for the sensor shield can be found on ROHM’s website
◆ Materials： Circuit diagrams, manuals
◆ Software： Sample source code (Arduino Uno, mbed）
Click on the following URL for additional information.
Sensor Shield Web Page: http://www.rohm.com/sensor-shield-support

Terminology

Arduino
A popular open-source platform supplied by Arduino consisting of a development environment and board equipped with input/output ports and an MCU. Arduino Uno is the most popular board in the Arduino family.

mbed
Refers to a prototyping MCU board and development environment supplied by ARM.

Open Platform
A model promoting the universal (public) access of program source code, product lists, detailed specifications, and other information, allowing anybody to copy, modify, and distribute freely.
