PSR100KTQFL3L00

6432 (2512) size, 4W, 3mΩ, High Power Type Metal Plate Shunt Resistor (AEC-Q200 Qualified)
Data Sheet Buy
PSR100KTQFL3L00

PSR100KTQFL3L00
6432 (2512) size, 4W, 3mΩ, High Power Type Metal Plate Shunt Resistor (AEC-Q200 Qualified)

PSR100 series is ideal for current detection under high current circuit.

Optimized for a variety of applications, from wearable devices to automotive systems and industrial equipment

Data Sheet Buy
Data Sheet Buy

Lineup


* Fractions not supported (decimals only)

Product Detail


Part Number | PSR100KTQFL3L00
Status | Recommended
Package | PSR100
Packing Type | Taping
Unit Quantity | 5000
Minimum Package Quantity | 5000
RoHS | Yes
Product Longevity Program | 10 Years

Specifications:

Automotive grade

Yes

Size[mm](inch)

6432(2512)

Rated Power[W]

4, 3

Resistance Tolerance

F (±1%)

Resistance range[Ω]

3m

Temperature Coefficient[ppm/°C]

0～+50

Operating Temperature[°C]

-65 to 175

Type

For current sensing

Operating Temperature (Max.)[°C]

175

Common Standard

AEC-Q200 (Automotive Grade)

Find Similar

Features:

  • High power max 15W
  • Ultra low resistance range (0.1mΩ or more).
  • Excellent TCR characteristic
  • Convex structure
  • ROHM resistors have obtained ISO9001 / IATF16949 certification.
  • Corresponds to AEC-Q200.
