BD87584YFV-C
EMARMOUR™, Automotive Excellent EMI Characteristics Input/Output Rail-to-Rail CMOS Operational Amplifier
BD87584YFV-C
EMARMOUR™, Automotive Excellent EMI Characteristics Input/Output Rail-to-Rail CMOS Operational Amplifier
BD87584YFV-C is input/output Rail-to-Rail CMOS operational amplifier. An operating voltage range is wide with 4V to 14V. This operational amplifier is the most suitable for automotive requirements such as sensor amplifier, engine control unit, electric power steering, anti-lock braking system and so on because it has features of high slew rate and low input bias current. Furthermore, they have the advantage of EMI tolerance. It makes easier replacing with conventional products or simpler designing EMI.
Product Detail
Functional Safety:
Specifications:
Channel
4
Package
SSOP-B14
Package Size [mm]
5.0x6.4 (t=1.35)
Operating Temperature (Min.) [°C]
-40
Power Supply (Min.) [V] (+5V=5, ±5V=10)
4
Operating Temperature (Max.) [°C]
125
Power Supply (Max.) [V] (+5V=5, ±5V=10)
14
Input Voltage Range [V]
VSS to VDD
Circuit Current (Typ.) [mA/ch]
2.5
Output Voltage Range [V]
VSS+0.03 to VDD-0.05
Input Offset Voltage (Max.) [mV]
9
GBW (Typ.) [MHz]
4
Output current (Typ.) [mA]
3.5
Slew Rate (Typ.) [V/µs]
3.5
Voltage gain (Typ.) [dB]
110
Input Bias Current (Typ.) [nA]
0.001
CMRR (Typ.) [dB]
60
PSRR (Typ.) [dB]
80
I/O
Rail-to-Rail Input/Output
Reference Code
TSSOP-14
Common Standard
AEC-Q100 (Automotive Grade)
Features:
- EMARMOUR™ Series
- AEC-Q100 Qualified (Grade 1)
- Input/Output Rail-to-Rail
- Low Supply Current
- Wide Operating Supply Voltage Range
- High Open Loop Voltage Gain
