ROHM has Developed Ultra-Compact CMOS Op Amp: Delivering Industry-Leading* Ultra-Low Circuit Current

*September 9th, 2025 ROHM study on ultra-low current products under 500nA

September 9th, 2025

TLR1901GXZ

ROHM’s ultra-compact CMOS Operational Amplifier (op amp) TLR1901GXZ achieves the industry’s lowest operating circuit current. This IC is optimized to be applied as a measurement sensing amplifier in size-constrained applications such as handheld measurement instruments, wearable devices, and indoor motion detectors.

As the demand continues to grow for more sophisticated control in battery-driven devices, the importance of sensors that detect parameters such as temperature, humidity, vibration, pressure, and flow rate – along with the op amps used to amplify these sensor signals – continues to rise. At the same time, greater miniaturization and energy savings in applications is a necessary step to realizing a sustainable society –placing similar demands on individual devices as well.

In response to these evolving market needs, ROHM has advanced its process, packaging, and proprietary Nano Energy™ circuit technologies to develop an op amp that addresses three key requirements: lower power consumption, higher accuracy, and compact size. The newly developed TLR1901GXZ achieves an ultra-compact footprint of less than 1mm2 by adopting a WLCSP (Wafer Level Chip Scale Package) with a fine ball pitch of 0.35mm while delivering an industry-leading low operating current of 160nA (typ.). This not only contributes to high-density mounting in space-constrained applications, but also to a significantly extended battery life.

Moreover, the TLR1901GXZ features an exceptionally low input offset voltage of just 0.55mV (max.), one of the best among ultra-low current op amps. This represents an approximate 45% reduction compared to typical products on the market. A maximum input offset voltage temperature drift of 7uV/°C ensures high accuracy operation over the operating temperature range.

Design flexibility can be further enhanced by pairing the op amp with ROHM’s ultra-compact general-purpose resistors, such as the MCR004 (0402 metric / 01005 inch) and MCR006 (0603 metric / 0201 inch), for applications like gain adjustment. The MCR004 series lineup includes the MCR004E –an environmentally friendly, fully lead-free option designed to support sustainable designs. Adapter boards featuring SSOP5 package ICs are offered as well to support initial evaluation and replacement assessments.

Going forward, ROHM will continue to pursue further power savings in op amps by advancing both miniaturization and original ultra-low power technologies. At the same time, we are committed to improving device performance by reducing noise and offset, expanding power supply voltage ranges, and contributing to solving social issues through more precise application control.

Comparison of Low-Power Op Amp Characteristics

Key Product Characteristics

　　
Part No. Data
Sheet		 No. of
Circuits		 Supply
Voltage
[V]		 Circuit
Current
Typ.
[nA]
(Ta=25°C)		 Max.
Input
Offset
Voltage
[mV]
(Ta=25°C)		 Max.
Input
Offset
Voltage
Temperature
Drift
[uV/°C]		 Operating
Temperature
[°C]		 Package
[mm]
NewTLR1901GXZ PDF 1 1.7
to
5.5		 160 0.55 7.0 -40
to
+85		 XCSP30L1
XCSP30L1
(0.91×0.80,
H = Max. 0.33)

Application Examples

• Consumer devices: wearables, smart devices, motion sensors, etc.
• Industrial equipment: gas detectors, fire alarms, handheld measurement instruments, environmental sensors for IoT, etc.

Online Sales Information

Sales Launch Date: Now
Pricing: $2.1/unit (samples, excluding tax)
Online Distributors: DigiKey and Mouser
• Applicable Part No: TLR1901GXZ-E2

Online Distributors

  • DigiKey
  • Mouser

• IC-Mounted Adapter Board: TLR1901GXZ-EVK-001

IC-Mounted Adapter Board [TLR1901GXZ-EVK-001]

What is Nano Energy™ Technology?

Nano Energy™ refers to proprietary ultra-low current consumption technology that achieves a current consumption on the order of nano ampere (nA) by combining advanced analog technologies covering circuit design, layout, and processes utilizing ROHM’s vertically integrated production system.
This contributes not only to extending operating time of battery operated IoT and mobile devices, but also improving efficiency in industrial and automotive equipment where increased power consumption is problematic.
https://www.rohm.com/support/nano

Nano Energy™

Nano Energy™ is a trademark or registered trademark of ROHM Co., Ltd.

Terminology

WLCSP (Wafer Level Chip Scale Package)
An ultra-compact package in which terminals and wiring are formed directly on the wafer before separated into individual chips. Unlike general packages where the chips are cut from wafers and then molded with resin to form terminals, WLCSP allows the package size to match the chip itself, making it possible to further reduce size.
Input Offset Voltage
The small voltage difference that must be applied between the inverting and non-inverting inputs of the operational amplifier to make the output voltage exactly zero.
Input Offset Voltage Temperature Drift
Refers to how much an op amp's input offset voltage changes as the temperature changes.
