pcim

SMALLER STRONGER FASTER

ROHM Expands its Range of Power Devices to
Offer Complete Power Solutions

New lines include latest SiC based technologies and
Si based IGBT devices for enhanced energy efficiency.

ROHM Semiconductor will showcase its latest power product designs at PCIM, the leading trade fair for Power Electronics, Intelligent Motion and Energy Management in Nuremberg, from June 05 – 07, 2018 (Hall 9, Booth 316). Energy savings and reduced system costs in all kinds of systems are heavily influenced by choosing the right power device. With its new developments resulting from the group's extensive research and design initiatives, ROHM is able to offer customers not only a full line-up of efficient, compact products for their applications, but also a complete solution for the power channel. ROHM will show power semiconductor solutions with 5 categories as ‘SiC', ‘Power IC', ‘Automotive', 'Industrial' and ‘Motor Drive',

Booth: Hall 9-316

Date: June 05 (Tue) – June 07 (Thu) 2018
Venue: Nuremberg, Germany | Booth: Hall 9-316
Website: http://www.mesago.de/en/PCIM

Highlights:

SiC MOSFET Gate Driver

The new series of Isolated Gate Driver ICs for power MOSFETs will expand the existing portfolio, offers new solutions to increase the flexibility and improves the design of industrial and automotive power systems. The first product of this series is a 3,75KV isolation, AEC-Q100 gate driver device specifically designed to drive a SiC power MOSFET. It has an output current of 4A, a built-in active miller clamping to prevent parasitic turn on effects and integrates an under-voltage lock-out (UVLO) optimized to drive ROHM's SiC MOSFET. The optimized UVLO improves the reliability of the system – a very sensitive topic in Automotive and Industrial applications. Moreover the integration of this function minimizes the external BOM, reducing the PCB layout space and design effort.

1200V 400A/600A Full SiC Power Modules

The new 1200V 400A and 600A full SiC power modules incorporate latest SiC MOSFETs and SiC SBDs with a new low inductance structure. The provided function of good flatness baseplate allows reducing the thermal resistance value between module-case and heatsink which enables a smaller size of the cooling system.

Latest SiC-SBDs with 650V rating

Superior reverse recovery of SiC SBDs is effective to apply high switching speed application like as CCM-PFC as already known. The new SiC SBDs also has low forward voltage characteristics, especially improved in high temperature range. This is effective to reduce also conduction loss in application. Latest portfolio is expanded standard and full molded TO-220-2pin and TO-263.

New IGBT Line-up

Based on thinner wafer, field stop and a sophisticated proprietary Trench Gate structure technologies, ROHM's new 650V IGBTs are overcoming the trade-off between saturation voltage and turn-off loss characteristics. On top of this, measurement results show low noise performance while keeping higher switching speed. The new generation includes two variants: The RGTV series with advanced short circuit safety, as well as the RGW series for converters with a low gate charge, capacitance and extremely low switching loss. Both are integrated with a very fast and soft recovery FRD, providing optimum efficiency to applications.

Automotive IGBT

ROHM's RGS series is automotive graded switching IGBT with high robustness against short circuit failure. RGS series acquires two types of collector-emitter Voltage - 650V guaranteed 8us short circuit withstand and 1200V with 10us short circuit withstand time. They can be selected according to battery size of electric vehicles. RGS series is suitable to automotive e-compressor and PTC heater application.

Power Management IC

Based on long term experience with Discrete Power Devices, ROHM Semiconductor offers a broad lineup of Power Management ICs for Automotive, Industrial and Consumer market. This includes isolated DCDC regulators like the BD7Fxx or BD7Jxx series as well as optimized ACDC converters which allow to build-up high efficient power supplies based on SiC technology. In addition ROHM continues to stretch the limits of what is possible with new concepts like a Quick Buck Boost Converter or ROHMs Nano-Pulse technology.



PCIM2018 Presentations

Presentations

For people interested in details of the new technologies, ROHM staff members will give various presentations in several areas of the fair ground:

Industrial Forum:

  Date Time Room Topic Presenter Add to calender
1 Thu, 7 June 13:45 – 14:45 Hall 6, booth 155 SiC Solutions for Industrial and Automotive Application Aly Mashaly calender

E-mobility Forum:

  Date Time Room Topic Presenter Add to calender
1 Tue, 5 June 11:30 – 12:00 Hall 6, booth 320 SiC Solutions for E-Mobility Tomonori Hoki calender
2 Wed, 6 June 11:30 – 12:00 TBA SiC Solutions for E-Mobility Tomonori Hoki calender

Vendor Presentation:

  Date Time Room Topic Presenter Add to calender
1 Thu, 7 June 14:20 – 14:40 hall 7, booth 507 SiC & power device update ROHM Semiconductor Jochen  Hueskens calender

Bodo’s Power Podium Discussion

  Date Time Room Topic Presenter Add to calender
1 Wed, 6 June 13:30 – 14:30 Hall 6, booth 143 SiC – Devices for the Future Design Guenter Richard calender

Conference Program:

  Date Time Room Topic Presenter Add to calender
1 Tue, 5 June 11:50 – 12:15 Room München 2 Automotive Traction Inverter Utilizing SiC Power Module Masaharu Nakanishi calender
2 Tue, 5 June 15:15 – 17:30 Foyer Ground Floor Entrance High Reliable 1700V Full SiC Power Module Kenji Hayashi calender
3 Wed, 6 June 14:00 – 14:25 Room Mailand S-parameter Based Simulation Modeling a Power Module Independent of Measurement Data Junichi Kashiwagi calender
4 Wed, 6 June 14:25 – 14:50 Room Mailand Electro-Thermal Simulation for Predicting the Temperature of SiC Dies in the Power Module of a High Frequency Operating Power Converter Yohei Nakamura, calender
5 Thu, 7 June 14:25 – 14:50 Room München 2 A Trans-Linked 5-kW Inverter Using SiC MOSFETs to Achieve Fan-less Operation Tatsuya Miyazaki calender
